| Dimensions | Depth | 208 mm (8.19 in.) |
| Height | 473.6mm (18.65 in.) |
| Width | 608.60 mm (23.96 in.) |
| Stand | Tilt | -5° to 35° |
| VESA mount | Supported | 100 mm x 100 mm (3.94 in. x 3.94 in.) |
| Image | Viewable image size | 685 mm (27 in.) |
| Maximum height | 608.6 mm (23.96 in.) |
| Maximum width | 596.736 mm (23.49 in.) |
| Pixel pitch | 0.2331mm (0.01 in.) |
| Power input | Supply voltage | 100-240V AC |
| Max supply current | 1.5A |
Power consumption Note: Power consumption figures are for the monitor and the power supply combined. Note: Typical power
consumption is tested
under OSD default
setting | Normal operation | <40 W (Typical), <15W (Max) |
| Standby/Suspend | <0.5 W |
| Off | <0.3 W at 100VAC and 240VAC |
|
| DP | Interface | DP |
| Input Signal | VESA TMDS (Panel Link™) |
| Horizontal addressability | 2560 pixels (max) |
| Vertical addressability | 1440 lines (max) |
| Clock frequency | 300 MHz (max) |
| HDMI | Interface | HDMI |
| Input Signal | VESA TMDS (Panel Link™) |
| Horizontal addressability | 2560 pixels (max) |
| Vertical addressability | 1440 lines (max) |
| Clock frequency | 300 MHz (max) |
| Communications | VESA DDC | CI |
| Supported Display Modes | Horizontal frequency | 30 kHz – 114 kHz |
| Vertical frequency | 48 Hz – 75 Hz |
| Native Resolution | 2560 x 1440 at 60 Hz |
| Temperature | Operating | 0° to 40°C (32°F to 104° F) |
| Storage | -20 to 60° C (-4° to 140° F) |
| Shipping | -20 to 60° C (-4° to 140° F) |
| Humidity | Operating | 10% to 80% non-condensing |
| Storage | 5% to 95% non-condensing |
| Shipping | 5% to 95% non-condensing |
